PCB Assembly & Manufacturing Common Materials
PCB Assembly & Manufacturing Common Materials include FR-4, high-frequency laminates, metal core substrates, and specialty materials, providing reliable electrical performance, thermal stability, and compatibility with diverse PCB and PCBA applications.
Standard and specialty PCB laminate materials
Reliable thermal and electrical performance
Compatible with diverse PCB applications
Common Materials
PCB Production Common Materials
PCB Production Common Materials include FR-4, high-speed, metal core, and specialty laminates to support reliable and diverse applications.
FR-4
Excellent Cost and Reliability Balance
FR-4 is the most widely used PCB material, offering stable electrical performance, good mechanical strength, and cost-effective manufacturing.
High TG FR-4
Enhanced Thermal Resistance
High TG FR-4 provides improved heat resistance and dimensional stability, making it suitable for multilayer and lead-free PCB applications.
FR-4
Low Loss High-Frequency Performance
Rogers material delivers low dielectric loss and stable signal transmission, ideal for RF, microwave, and high-speed circuit designs.
Aluminum Core PCB
Superior Heat Dissipation
Aluminum core material offers excellent thermal conductivity and mechanical strength, widely used in LED lighting and power electronics.
Polyimide Material
High Flexibility and Heat Resistance
Polyimide material provides outstanding flexibility and temperature resistance, supporting flexible and rigid-flex PCB applications.
Ceramic Substrate
High Thermal and Electrical Stability
Ceramic substrates feature excellent thermal conductivity and insulation properties, suitable for automotive and high-power electronic devices.
Aluminium
Tg
Product
Manufacturer
130
T-111
Totking
170
92ML
Arlon
185
HPL-03015
Bergquist
105
T-Lam 6061+ 1KA10
Laird
120
KW-ALE
Kinwong
140
DST-5000
Doosan
140
T-Lam 5052 + 1KA04
Laird
170
VT-4A2
Ventec
105
ML1KA
Laird
105
SS1KA
Laird
105
T-Lam - Alco 6061+ 1KA04
Laird
105
TLam SS 1KA06
Laird
110
TCP-1000
Bergquist
120
KW-ALS
Kinwong
130
CML-11006
Bergquist
130
IT-859GTA
ITEQ
130
SA115
Shengyi
130
SA120
Shengyi
140
SAR15
Shengyi
140
SAR20
Shengyi
150
HT-04503
Bergquist
150
HT-07006
Bergquist
150
HT-09009
Bergquist
165
SSLLD
Laird
168
SSHTD04
Laird
168
SSHTD06
Laird
170
92ML Dielectric
Arlo
170
VT-4A1
Ventec
90
LTI-04503
Bergquist
90
LTI-06005
Bergquist
90
MP-06503
Bergquist
CEM-1
Tg
Product
Manufacturer
110
S3110
Shengyi
130
KB-5150
Kingboard
CEM-3
Tg
Product
Manufacturer
130
DS-7209
Doosan
130
R1786
Panasonic
128
S2155
Shengyi
130
CEM-3-98
Nanya
130
KB-7150
Kingboard
130
S2600
Shengyi
132
S2130
Shengyi
135
CEM-3-09HT
Nanya
140
R-1786
Panasonic
Ceramic
Tg
Product
Manufacturer
250
RO4500
Rogers
Embedded Capacitance
Tg
Product
Manufacturer
120
C0614
3M
120
C1012
3M
120
C2006
3M
Epoxy PTFE
Tg
Product
Manufacturer
210-240
N4350-13RF
Nelco
210-240
N4380-13RF
Nelco
FR-1
Tg
Product
Manufacturer
130
KB-3150N
Kingboard
FR-4
Tg
Product
Manufacturer
140
MTC-97
Grace
155
DE156
Isola
170
IS420
Isola
170
NPGN-170R (HF)
Nanya
170
TU-862 HF
Taiwan Union
180
185HR
Isola
180
I-Speed
Isola
180
TU-752
Taiwan union
150
NPGN-150
Nanya
180
G200
Isola
130
GA-140-LL
Grace
130
KB-6150
Kingboard
130
Tlam SS 1KA
Laird
133
R-1755E
Panasonic
135
DE104ML
Isola
135
DS-7405
Doosan
135
H140-1 / FR-4-74
HuaZheng
135
IT-588
ITEQ
135
KB-6160
Kingboard
135
KB-6160A
Kingboard
135
KB-6160C
Kingboard
135
R1755C
Panasonic
135
S1130
Shengyi
135
S1155
Shengyi
135
S1600
Shengyi
140
FR-4-86
Nanya
140
FR-402 / IS402
Isola
140
IT-140
ITEQ
140
KB-6164
Kingboard
140
LYCCL-140
LongYu
140
NP-140TL
Nanya
140
NY-1140
Nanya
140
S1141
Shengyi
140
TC-97
Grace
145
ELC-4765
Sumilite
145
IT-150TC
ITEQ
148
R-1566(W)
Panasonic
150
250HR
Isola
150
254
Isola
150
EM-285
Elite Material
150
EM-825
Elite Material
150
GA-150-LL
Grace
150
GW1500
GoWorld
150
IS400
Isola
150
IT-158
ITEQ
150
IT-158TC
ITEQ
150
IT-258GA
ITEQ
150
KB-6150
Kingboard
150
NP-150R
Nanya
150
NP-150TL
Nanya
150
TU-668
Taiwan Union
150
TU-742 HF
Taiwan Union
150
TU-747 HF
Taiwan Union
155
N4000-7
Nelco
155
NP-155FR
Nanya
155
NP-155FTL
Nanya
155
NY-2150
Nanya
155
S1000
Shengyi
155
S1000H
Shengyi
155
S1150, S1150G
Shengyi
160
TU-662
Taiwan Union
170
EM-320
Elite Material
170
EM-370
Elite Material
170
EM-827
Elite Material
170
FR-406
Isola
170
GA-170-LL
Grace
170
KB-6167
Kingboard
170
NP-170R
Nanya
170
NP-170TL
Nanya
170
S1165
Shengyi
170
S1170
Shengyi
175
370 Turbo
Isola
175
EM-827/ EM-827B
Elite Material
175
IT-180
ITEQ
175
IT-180A
ITEQ
175
N4000-11
Nelco
175
N4000-6
Nelco
175
NP-175TL
Nanya
175
NP-180R
Nanya
175
S1000-2M
Shengyi
175
TU-722
Taiwan Union
176
R5725 Megtron 4
Panasonic
180
370HR
Isola
180
FR-408
Isola
180
IS410
Isola
180
KB-6168
Kingboard
180
Megtron R-5715
Panasonic
180
N4000-12
Nelco
180
S1000-2
Shengyi
180
Theta 100
Rogers
180
TU-768
Taiwan Union
180
VT-47
Ventec
185
N4000-29
Nelco
190
FR-408HRIS
Isola
200
FR-408HR
Isola
200
IS415
Isola
210
N4000-13
Nelco
210
N4000-13EP
Nelco
210
N4000-13SI
Nelco
210
N4103-13
Nelco
210
S1860
Shengyi
225
IS620
Isola
250
Arlon 85N
Arlon
250
VT-901
Ventec
260
N-7000
Nelco
280
RO3010
Rogers
280
RO4003C
Rogers
280
RO4350
Rogers
280
RO4350B
Rogers
Polyimide
Tg
Product
Manufacturer
260
P95 & P25
Isola
N/A
FR9111
DuPont
N/A
THKD101020JY
Taiflex
185
LF9121
DuPont
220
AP-9111
DuPont
220
AP-9121R
DuPont
220
AP-9131
DuPont
250
35N
Arlon
250
85N
Arlon
250
FR9111
DuPont
320
X-0505ES-N2
ThinFlex
340
RF775
Panasonic
343
RF770
Panasonic
N/A
CMT300XMM1
Grace
N/A
SF201
Shengyi
N/A
SF202
Shengyi
N/A
SF302
Shengyi
N/A
SF305
Shengyi
N/A
THKS050513
Taiflex
ThinFlex-A
ThinFlex
Polyphenyl E-Glass
Tg
Product
Manufacturer
180
Getek
Isola
PPO Blend Resin
Tg
Product
Manufacturer
185
Megtron 6
Panasonic
PTFE (Ceramic filled)
Tg
Product
Manufacturer
RO3003
Rogers
PTFE - Glass
Tg
Product
Manufacturer
280
TLP-5
Panasonic
PTFE
Tg
Product
Manufacturer
250
RT5880 (Duroid)
Rogers
N/A
N9350
Nelco
PTFE Ceramic filled
Tg
Product
Manufacturer
AD350A
Arlon
PTFE Coated Ceramic
Tg
Product
Manufacturer
315
RF-35
Taconic
CLTE-XT
Arlon
PTFE E-Glass
Tg
Product
Manufacturer
200
DiClad 880
Arlon
210
TLX-8
Taconic
210
TLX-9
Taconic
PTFE/Woven Glass
Tg
Product
Manufacturer
280
250GT
Arlon
Stainless Steel
Tg
Product
Manufacturer
110
KW-ALS
Kinwong
XPC
Tg
Product
Manufacturer
100
KB-1150
Kingboard
The table above only lists process parameters for HDI PCB products. Please download the full process manual.
Material Source
PCB Production Common Materials Source
PCB Production Common Materials Source relies on qualified global suppliers to ensure consistent quality, stable performance, and reliable material traceability for diverse PCB manufacturing requirements.
3M
Dow
Pnot
rogers
tesa
titeq
生益科技
松下
台光
台虹科技
台耀
Packaging Standards
PCB Production Packaging Standards
PCB Production Packaging Standards ensure safe handling, moisture protection, and reliable transportation, preserving product quality and preventing damage during storage and shipment.
01
Packaging Principles
Proper packaging principles ensure PCB products are protected from moisture, impact, and electrostatic damage during storage and transportation, maintaining quality and delivery reliability.
Moisture-proof, anti-static, and shock-resistant protection
Clear labeling for traceability and shipment control
Secure packaging to prevent deformation and damage
02
Packaging Materials
Standard packaging materials are selected to provide effective moisture resistance, anti-static protection, and mechanical support, ensuring PCB products remain intact and reliable throughout storage and international transportation.
Vacuum bags with desiccants for moisture protection
ESD shielding materials for static-sensitive products
Cartons and cushioning materials for impact resistance
03
Packaging Process
The packaging process follows strict handling and protection procedures, including drying, vacuum sealing, labeling, and reinforced packing to ensure PCB products remain safe from moisture, static, and mechanical damage during logistics and storage.
Drying, vacuum sealing, and reinforced protective packing steps
Strict ESD control and moisture prevention during handling
Clear labeling and inspection before final shipment release
Logistics Standards
PCB Production Logistics Standards
PCB Production Logistics Standards ensure secure handling, efficient shipment scheduling, and reliable global delivery, maintaining product integrity and on-time arrival for all PCB orders.
Logistics Philosophy
STANDARDIZED
PCB Logistics Management
Shipping Control
Shipping control ensures PCB products are properly scheduled, packed, and tracked to maintain safe and on-time global delivery.
Global Distribution
Global distribution supports efficient international delivery, ensuring PCB products reach customers quickly and reliably.
Damage Prevention
Damage prevention focuses on protecting PCB products from impact, moisture, and static during transportation and handling.
Delivery Assurance
Delivery assurance guarantees accurate order fulfillment and on-time arrival, improving customer trust and supply reliability.
