Flex Assembly Capabilities
Flex Assembly Capabilities include precision flexible circuit assembly, fine-pitch component placement, controlled soldering processes, and strict inspection systems, ensuring reliable electrical performance and durable PCB flexibility.
Manufacturing Process
Key Factors in Flex Assembly
Reliable flex assembly requires precise component placement, controlled bending design, optimized soldering processes, and careful handling to ensure stable electrical performance and long-term mechanical reliability.
Material Flexibility Control
Key Factors in Flex Assembly include strict material flexibility control to ensure stable bending performance, preventing cracks and deformation while maintaining reliable electrical conductivity in dynamic flexible PCB applications.
01
Thermal Management Design
Key Factors in Flex Assembly rely on precision alignment control during component placement to ensure accurate positioning, stable solder joints, and consistent electrical performance across high-density flexible circuit structures.
02
Thermal Process Stability
Key Factors in Flex Assembly emphasize thermal process stability during soldering and reflow, ensuring uniform heat distribution, preventing delamination, and maintaining reliable interconnection in flexible PCB assemblies.
03
Mechanical Stress Management
Key Factors in Flex Assembly require effective mechanical stress management to reduce strain during bending and operation, ensuring long-term durability and stable signal transmission in flexible electronic systems.
04
Manufacturing Capability
Production Capacity Table
Production Capacity Table for Flex Assembly provides clear visibility of flexible PCB assembly capability, throughput, inspection coverage, and delivery capacity, enabling efficient planning and stable execution for complex flexible electronics manufacturing.
Item
Capability
Assembly Type
SMT, THT, Mixed Technology
PCB Size
Min. 50 × 100 mm，Max. 510 × 480 mm
Board Type
Rigid, Flex, Rigid-Flex, Aluminum PCB, Ceramic PCB
Assembly Standard
IPC-A-610 Class 2 / Class 3
Lead-Free Process
Available
RoHS & REACH Compliance
Yes
ESD Protection
ANSI/ESD S20.20
Minimum Chip Size
01005 (0.4 × 0.2 mm)
Fine Pitch IC
0.30 mm
Minimum BGA Pitch
0.30 mm
Maximum BGA Size
80 × 80 mm
BGA Ball Count
Up to 3000 Balls
Maximum Component Height
40 mm
Maximum Component Weight
100 g
The table above only lists process parameters for HDI PCB products. Please download the full process manual.
